H-post support bracket 116mm
SKU 21195116
+ Available in hot-dip galvanizing or stainless steel
+ Available up to 8mm steel thickness
+ Extremely high thermal galvanisation of 60 microns
+ Prevents wood rot, wooden poles are fixed above the ground, no contact with rainwater and moisture
+ Carriage bolts to fix wooden posts available as an option
Delivery in 5-21 days
Product description
H-Post Support Bracket 116mm 600mm Hot-Dip Galvanized
The H-post support bracket 116mm (116x600x60x5.5mm) is a heavy-duty steel post holder designed for secure installation of large wooden fence posts in concrete. Its robust H-shaped design ensures maximum strength, stability and load distribution for demanding outdoor structures.
The hot-dip galvanized finish provides excellent protection against rust and long-term weather exposure.
Advantages of the H-Post Support Bracket
- Extra strong H-shaped steel construction
- Hot-dip galvanized for maximum corrosion resistance
- Designed for installation in concrete
- Suitable for 116mm wooden fence posts
- 5.5mm thick steel for heavy-duty performance
- High stability for permanent fencing systems
Technical Specifications
- Product: H-post support bracket / post base
- Dimensions: 116x600x60x5.5mm
- Material: Steel
- Finish: Hot-dip galvanized
- Top internal size: 116mm
- Installation type: In concrete
- Application: Garden fencing and heavy-duty structural support
Applications
This H-post support bracket is suitable for securing large wooden posts in concrete for garden fencing, boundary structures, pergolas and other heavy outdoor constructions requiring maximum stability and durability.
Installation Guide
- Dig a hole for the concrete foundation.
- Position the H-post support bracket correctly.
- Pour concrete and ensure alignment.
- Allow concrete to fully cure.
- Insert and secure the wooden post into the bracket.
Related Products
Complete your fencing project with matching components such as wooden fence posts, fixings and fence hardware, wooden fences, natural privacy fences.
FAQ – Frequently Asked Questions
What makes this bracket heavy duty?
The 5.5mm thick steel and H-shaped construction provide exceptional strength and durability.
Is it suitable for concrete installation?
Yes, it is designed specifically for embedding in concrete.
What post size fits this model?
It is suitable for 116mm wooden fence posts.
Is it suitable for large structures?
Yes, it is ideal for heavy-duty fencing and structural applications requiring high stability.
